Rim formwork tie plane

An anchor for mounting 18 mm thick concrete plywood as edge formwork at the site of an anchorless cavity wall.

Wood Size width

19 mm

20 mm

Details & dimensions

Article number10035

EAN code8714318010126

EAN code8714318108809

Packaging100 per box

Length330 mm

Width230 mm

Height130 mm

Width (b)30 mm

Thickness (d)2 mm

Hole pattern5/3-2/4,5-1/6,5

Wood Size width19 mm

Typeflat AS

MaterialSteel

Steel QualityDX51

Surface treatment

Drawings and models in 2D and 3D

Certifications, quality marks and technical sheets

1 / 4

View our assembly instructions here that help you step by step to an end result.

You can use the products below to place or confirm the product correctly.

Name	Article number	Packaging	Width	Thickness	Height 1	Receivers for	Hole pattern	Lip size	Wood Size width	Type	Material	Steel Quality	Surface treatment
Rim formwork tie plane	10035	100 per box	30 mm	2 mm	-	-	5/3-2/4,5-1/6,5	-	19 mm	flat AS	Steel	DX51
Rim shuttering anchor	101340	100 per box	30 mm	2 mm	20 mm	coreless cavity wall	5/3-2/4,5-1/6,5	15 mm	20 mm	20 AS	Steel	DX51
