Flex-5 plug

The green insulation plug is for mounting hard and soft cavity insulation in combination with UNI percussion cavity anchors Ø 5 mm in an internal wall of concrete, sand-lime brick or solid brick.

Length

Isolation thickness

Details & dimensions

Article

Article number333220

EAN code8714318068714

Packaging

EAN code8714318068721

Packaging250 per bag

Length700 mm

Width560 mm

Height200 mm

Dimensions

Flex-5 plug

Length (l)220 mm

Diameter8 mm

Isolation thickness161 t/m 180 mm

ColorGreen

Dish Ø60 mm

MaterialPlastic

Material quality

Surface treatment

Downloads

Drawings and models in 2D and 3D

Certifications, quality marks and technical sheets

Technical Sheet

Processing & accessories

1 / 5

View our assembly instructions here that help you step by step to an end result.

You can use the products below to place or confirm the product correctly.

Name	Article number	Packaging	Length	Diameter	Isolation thickness	Color	Dish Ø	Material
Flex-5 plug	333140	250 per bag	140 mm	8 mm	81 t/m 100 mm	Green	60 mm	Plastic
Flex-5 plug	333160	250 per bag	160 mm	8 mm	101 t/m 120 mm	Green	60 mm	Plastic
Flex-5 plug	333180	250 per bag	180 mm	8 mm	121 t/m 140 mm	Green	60 mm	Plastic
Flex-5 plug	333200	250 per bag	200 mm	8 mm	141 t/m 160 mm	Green	60 mm	Plastic
Flex-5 plug	333220	250 per bag	220 mm	8 mm	161 t/m 180 mm	Green	60 mm	Plastic
Flex-5 plug	333240	125 per bag	240 mm	8 mm	181 t/m 200 mm	Green	60 mm	Plastic
Flex-5 plug	333260	125 per bag	260 mm	8 mm	201 t/m 220 mm	Green	60 mm	Plastic
Flex-5 plug	333280	125 per bag	280 mm	8 mm	221 t/m 240 mm	Green	60 mm	Plastic
Flex-5 plug	333300	125 per bag	300 mm	8 mm	241 t/m 260 mm	Green	60 mm	Plastic
Flex-5 plug	333320	125 per bag	320 mm	8 mm	261 t/m 280 mm	Green	60 mm	Plastic
Flex-5 plug	333340	125 per bag	340 mm	8 mm	281 t/m 300 mm	Green	60 mm	Plastic
Flex-5 plug	333360	125 per bag	360 mm	8 mm	301 t/m 320 mm	Green	60 mm	Plastic
