Cavity anchor with percussion thread for use in combination with collar plug, UNI flex plug or UNI renovation plug. For mounting in internal concrete, sand-lime brick or brick walls. On the outside, the cavity anchor has a corrugated profile to be grouted in.
Length
Diameter
4 mm
5 mm
Cavity Size
Environmental class
MX 1
MX 4
Material
RVS 316
Steel
Steel Quality
DX51
W-Nr.: 1.4401-1.4362
Surface treatment
316 O.G.
VD
Details & dimensions
Article
Article number374663
EAN code8714318060206
Packaging
EAN code8714318060213
Packaging250 per box
Length550 mm
Width190 mm
Height85 mm
Dimensions
UNI-self tapping wall tie
Length (l)425 mm
Diameter4 mm
Cavity Size320 +/- 15 mm
Environmental classMX 4
Impact WireSL 4,6x60 mm
MaterialRVS 316
Steel QualityW-Nr.: 1.4401-1.4362
Surface treatment316 O.G.
Downloads
Drawings and models in 2D and 3D
Processing & accessories
1 / 5
View our assembly instructions here that help you step by step to an end result.
You can use the products below to place or confirm the product correctly.
