Barrel bolt

Sliding bolt with extended handle. Suitable for securing (double) doors at the top.

Length
Steel Quality
S235
S350
Surface treatment

Details & dimensions

Article

Article number74310
EAN code8714318075880

Packaging

EAN code8714318075880
Packaging1 piece
Length1000 mm
Width100 mm
Height40 mm

Dimensions

Barrel bolt

Length (l)1000 mm
Thickness (d)2 mm
Hole pattern10/5-4/5,5
Backplate83x120 mm
Result pen55 mm, pinion Ø18
Attachmentsincluding plate + 2 brackets
MaterialSteel
Steel QualityS235
Surface treatmentEPZ

Downloads

Drawings and models in 2D and 3D
